With a minimum starting size of 200ml and a maximum of 350ml, our system is perfectly tailored for producing small yet high-value resin prints.
Small resin tank for AccuFab-L4D/K(optional for L4K)
- Size: 314 x 205 x 44mm
- Tank volume: min 200ml, max 350ml
- Over 96% of the surface points fit within ±0.1mm
- High luminance uniformity achieves up to 90%
- Provides not only the possibility to obtain features smaller than a pixel, but also a superior surface finish
High-quality optical module with long-life components. AccuFab-L4D/K’s 5 million layers tested in real dental clinic condition provides state-of-the-art reliability.
DCS (District cooling system) maintains the temperature of working screen under 40℃, while extending the 3D printer lifespan significantly.
| Technical Specifications | |
|---|---|
| Printer Size | 360 x 360 x 530mm |
| Printer Weight | 19kg |
| Print Volume（x/y/z） | 192 x 120 x 180mm/ 70 x 70 x 180mm |
| Resolution | 3840 x 2400(4K)Px |
| Print Speed | Max 50 mm/h (depend on different material and layer) |
| Layer Thickness | 50 μm~100 μm (adjustable) |
| Accuracy | ± 50 μm |
